BWT bestprotect
The Protector
- Special filter system for gastronomy and bakeries
- Ideal for the production of hot beverages
- Very well suited for generating steam in combination steamers, steam cookers and ovens
- Protection against limescale and gypsum deposits
- Easy to install with universal BWT besthead FLEX connection technology
- Space-saving design that is very easy to handle
Product details
BWT bestprotect is a filter solution for water with special properties. It not only prevents the formation of limescale and gypsum, but also ensures a consistently high pH value.
BWT thereby protects the valuable machine technology from deposits and prevents corrosion problems on stainless steel parts. Moreover, this filter system delivers water with top sensory characteristics for producing high-quality hot beverages.
Technical advantages of BWT bestprotect at a glance:
- 5-stage filtration
- Reliable protection against limescale and gypsum for machines
- High pH value to minimise the risk of corrosion
- Activated charcoal fleece for consistently crystal-clear water
- Ease of handling when replacing the filter
Technical details
| BWT bestprotect type | S | V | XL | 2XL |
| Connection thread (in/out), (1) | 3/8" | 3/8" | 3/8" | 3/8" |
| Inlet pressure, min. – max. in bar | 2–8 | 2–8 | 2–8 | 2–8 |
| Water temperature, min. – max. in °C | 4–30 | 4–30 | 4–30 | 4–30 |
| Ambient temperature, min. – max. in °C | 4–40 | 4–40 | 4–40 | 4–40 |
| Total height without bracket in mm, approx. | 360 | 420 | 502 | 580 |
| Total height with bracket in mm, approx. | 385 | 445 | 527 | 600 |
| Connection height in mm | 306 | 366 | 448 | 520 |
| Distance to floor in mm | 65 | 65 | 65 | 65 |
| Installation length in mm | 125 | 125 | 125 | 125 |
| Ø filter cartridge in mm | 88 | 110 | 147 | 185 |
| Weight in kg, approx. (dry/wet) | 0.9/1.5 | 3.0/3.2 | 4.0/6.0 | 8.0/11.0 |
| Order no. of filter cartridge | FS22N00A00 | FS23N00A00 | FS28N00A00 | FS30N00A00 |
(1) Connection thread options with BWT besthead FLEX
